Cissoid PLUTO-C1230







CHT-PLUTO-C1230 is a high-temperature 1200V/30A Buck or Boost Module, i.e. a module including one Silicon Carbide (SiC) MOSFET and one SiC Schottky Diode, independent from each other.

PLUTO-C1230 Typical Performances

Temperature range: -55°C to +210°C

Drain voltage up to 1200V

Max drain current @ 175°C (Tc): 17A DC (per switch)

On-resistance Ron = 40mΩ @ 25°C and 120mΩ @ 210°C (per switch)

Gate-to-Source Voltage Vgs=-5V to +20V

PLUTO-C1230 Applications & Application Notes

DC motor drives and actuator control

DC-DC converters

AC-DC converters and inverters
